- motion detector for outdoor use
- two motion output channels with programmable timeout
- two light depending motion output channels with programmable light sensitivity and timeout
- dark and light output channels with programmable light sensitivity and timeout
- temperature sensor with low and high alarm output channels
- configuration with Velbuslink software (free) and USB/RS-232 interface module
- electronically addressable (up to 250 addresses)
- firmware can be upgraded through the Velbus system
- also available in white: VMBPIROW
Specifications
- Product basic info:
- Primary colours: Black
- Depth unit: 125 mm
- Height unit: 100 mm
- Width unit: 85 mm
- Weight unit: 194 g
- Electrical data:
- Current consumption: 25 mA
- Technical data:
- Mounting type: Wall mount
- Sensor head angle down: 30 °
- Sensor head angle left-right: 90 °
- Set-up options:
- Detection angle: 150 °
- Maximum detection range: 12 m
- Light sensitivity: 1-100 lx
- Adjustable angle: No
- Adjustable pan-tilt: No
- Environmental data:
- IP rating: IP55
- Operating temperature range: -25-45 °C
- Operational properties:
- Installation height: 2-4 m
- Power supply:
- Input voltage rating VDC range: 3-15 V
